The invention
Imagined by Kane in November 1979, at 23.
He then developed it with James Campbell, and together they went on to design and build solid-state digital media recorder/players. The first patent was applied for in 1981.
After years of development, and following the building of four prototype models, the fifth pre-production Pro recorder/player model went on sale at the APRS exhibition at Olympia, London.
- A portable player for audio, video and data, with no moving parts
- Content stored in solid-state memory
- Bought and loaded at a terminal from a distant location
- An optical fibre input for loading from a store in the shop or far away
- Copy control, The Birth of DRM
- Playlists, a screen and a four-way control
- Text and electronic reading
Patent GB 2 115 996, filed 2 November 1981 with James Campbell. Also granted as EP 0 092 558 and US 4,667,088.
Music was to be delivered to shops down telephone lines from a central data bank (IXI Systems outline, 1979).
Fast loading, at least 100 times faster than real-time playback.
Twenty-five years on, IXI’s US patent was cited as prior art in a California patent case.

The IXI Ecosystem as set out in the IXI patents and the 1979 IXI Systems report: content owners, a central data bank, royalties and DRM, shops and self-service stores, the IXI card and the IXI replay unit.
Read the text
The eight blueprint facts behind the IXI Ecosystem image: what each part does, what it is called today, and the wording of the IXI patents and the 1979 IXI Systems report.
Read the text
On-screen text of the IXI Ecosystem video (59 seconds, music, no narration). Five chapters build the 1979 diagram, then show Kane Kramer's original PC2 drawing and the IXI world at home, in the car and on the move.
Read the text
The firsts of IXI, 1979
The invention of the digital media player, music player and MP3 player, 1979
The iPod is a digital media player. Kane Kramer invented the digital media player, IXI, in 1979, together with the IXI ecosystem model that runs global digital commerce.
The firsts of IXI, 1979
- The Birth of the Digital Multi Media Player: a portable player for audio, video and data
- The digital music player: music stored digitally and played from a chip
- Solid-state memory with no moving parts
- The credit-card size removable memory card (the IXI card): the birth of the memory card
- The Birth of the Cloud concept: a remote Central Data Bank holding one master copy of every title
- A remote database and online catalogue, with any title available anywhere a terminal is installed, including rare and out-of-print titles
- The Birth of Streaming and Digital Downloads: music sent down phone lines or optical fibre
- Burst transfer at least 100 times faster than real time, so titles arrive in seconds
- The electro optical interface: optical fibre input and output with photoelectric conversion
- Online purchase: buy a title and get it at once, in the shop, then at home or anywhere
- The digital store: shop terminals program any title onto a blank card, so shops never sell out and hold no stock
- Self-service download kiosks: unattended coin or credit card stations with a keypad
- The Birth of DRM: copy control, with the card counting copies and stopping at a limit set by the rights owner
- Play-count limits and paid plays set by the rights owner
- Automatic royalty accounting: royalty splits for PRS, artists, writers and record companies, worked out in seconds
- Automatic retailer billing, commission and electronic payment by money or credit card
- Real-time sales chart updating from the central data bank
- Automatic stock monitoring and resupply of blank cards, and remote monitoring of kiosks
- A secure, encrypted, licensed digital distribution network against piracy, bootlegging and counterfeiting
- Music and its control data (metadata and rights) travelling together in one file
- Device-to-device copying and syncing: one card passes a digital copy to another
- Reprogrammable media: the same card loaded again with new content
- The first portable player navigated by a four-way control and on-screen menu, as shown in the ballpoint pen drawing (PIXY, PC2)
- A screen showing the track list, a library display and playlists
- A pocket player little larger than the card, with batteries and headphones
- Home and car units holding several cards and playing them in any order (shuffle and playlist playback)
- Display output to a VDU or screen
- Audio and video synchronisation, keeping a video recorder in sync
- Text and electronic reading: data, text, and scientific, medical and computer information, not only music
- The complete digital media ecosystem: content owners, the Cloud data bank, royalties and DRM, stores, kiosks, card and player, the model that runs global digital commerce
Sources: IXI patents GB 2 115 996, EP 0 092 558, US 4,667,088; IXI Systems report, 1979; the IXI Ecosystem video and drawings on this page.
IXI, 1979 to 2010
- 1979NovemberIXI imagined by Kane Kramer.
- 1980Letter on Bixpy Management notepaper describes a chip “in the form of a cassette or credit card”.
- 19812 NovemberPatent GB 2 115 996 filed.
- 19821 NovemberInternational patent application PCT/GB82/00311 filed, taking IXI to Europe, the USA and other countries.
- 198328 JuneLetter to Paul McCartney, “Re: PIXIE SYSTEMS”.
- 198314 SeptemberUK patent application published.
- 198321 DecemberLyricdata Ltd incorporated, the company behind the IXI prototypes.
- 198421 NovemberEgoroff & Associates: “firm commitments” to produce IXI memory packs.
- 198520 MarchUK patent GB 2 115 996 granted.
- 1985December“The Tapeless Studio?”, Sound Engineer + Producer.
- 19865 FebruaryEuropean patent EP 0 092 558 granted.
- 198625 to 27 JuneAPRS exhibition, Olympia, London.
- 198614 SeptemberThe Sunday Times: “Waxing lyrical over card-carried music”.
- 1987March“Solid State”, Hi-Fi Answers.
- 198719 MayUS Patent 4,667,088 granted.
- 200710 JulyKane recognised by Apple for his inventorship at 1 Infinite Loop; later an expert consultant.
- 20077 NovemberIXI’s US patent cited as prior art in a California patent case.
- 2010Sir James Dyson, Ingenious Britain.
Drawings, documents and prototypes
Each object is shown whole. Select an object to see it larger.
The idea
1979 to 1980Kane Kramer imagined IXI in November 1979, at the age of 23.
Nine typed pages from 1979: music held in a central data bank, sent by phone line to shops and copied onto a blank IXI chip.
Read the text
Albums and singles are stored in a computerised Central Data Bank and sent to a shop terminal, where they are put onto a blank IXI chip.
Read the text
Drawing PC2 of the PIXY hand-held player: a screen above a SELECT and PLAY pad, with - and + either side.
Read the text
Pencil sketch of the PIXY player, with a track-list screen, labelled controls and notes on colours and materials.
Read the text
Three graph-paper drawings of the PIXY: front views with SELECT, PLAY, VOL and ON, and a side profile.
Read the text
Drawings
1982Cross-section of a slim IXI player with labelled contacts, clip, card, headphones, display, keyboard and batteries.
Read the text
A shop counter under a VISUAL AUDIO sign, with listening stations and headphones.
Read the text
Patents
1981 to 1987Patent GB 2 115 996, filed 2 November 1981 with James Campbell. Also WO 83/01705, EP 0 092 558 and US 4,667,088.
UK application filed on 2 November 1981 by Kane Kramer and James Campbell, with the abstract and a block diagram of the card.
Read the text
US patent granted on 19 May 1987: filing data, the abstract and a block diagram of the credit-card-size system.
Read the text
Block diagram of the card: contacts, optical input and output, registers, controller, memory, decoders and mixer.
Read the text
Block diagram of the replay unit: optical connections, controller, decoders, channel filters and power supply.
Read the text
Prototypes and launch
1985 to 1986After years of development, and following the building of four prototype models, the fifth pre-production Pro recorder/player model went on sale at the APRS exhibition at Olympia, London.
A rack-style prototype photographed outdoors. The only lettering is on the keypad.
Read the text
The prototype with an IXI cartridge in front, labelled IXI CARTRIDGE, number 001.
Read the text
Press
1985 to 1987The cover lists the issue's features, producers, engineers and studios, including Digital Futures.
Read the text
Kane Kramer holds the prototype. Its front panel reads I.X.I. DIGITAL SYSTEMS.
Read the text
Report on the IXI prototype from Lyric Data of London: digital stereo on chip cartridges, three held at once, 10 minutes each.
Read the text
Kane Kramer with the prototype, reprinted. The front panel reads I.X.I. DIGITAL SYSTEMS.
Read the text
Part 2 of a feature on Lyricdata's IXI solid-state digital audio system, from a conversation with Kane Kramer.
Read the text
Correspondence
1980 to 1984Letters from Kane Kramer’s archive.
A typed note describing a chip in the form of a cassette or credit card that stores music and speech. The left edge is cut off.
Read the text
An outline of PIXIE SYSTEMS for Paul McCartney: a digital device of credit card size with no moving parts. Both pages are below.
Read the text
Why new formats struggle, a player price of £10 to £15, and funding. Signed Kane Kramer, copy to S. Shrimpton.
Read the text
Firm commitments to produce three ten-minute and three five-minute IXI non-volatile memory packs.
Read the text
Later recognition
2007 to 2010Kane was recognised by Apple in 2007 for his inventorship and has since acted as an expert consultant.
In 2008 Wired, the Daily Mail and Engadget reported Apple's recognition of Kane as the inventor of the digital audio player, after his evidence in Apple's 2007 patent case with Burst.com.
“the MP3 player was invented thirty years ago by a British innovator, Kane Kramer”
Sir James Dyson, Ingenious Britain, 2010
“The status quo is a wall that only moves when you push it with an idea that weighs nothing but changes everything.”
Orson Welles
Lettering visible in the three photographs: 1 Infinite Loop above the Apple entrance, and the Apple sign reading 10500 De Anza Three.
Read the text
Family album
Lettering visible in the family album: one photograph shows a sign reading To the Restaurant and Sculpture Gallery.
Read the text
Coming soon
Words by Kane Kramer.
